Google Expands TPU Supply Chain With Marvell Partnership

Google is in talks with Marvell Technology to develop two custom AI chips: a memory processing unit and a new inference-optimized TPU. The discussions, not yet a signed contract, would add Marvell as a third design services partner alongside Broadcom and MediaTek, while fabrication is expected to remain with TSMC. The plan targets inference-first operating economics as Google ramps production of Ironwood, its seventh-generation TPU (TPU v7).

The first chip is a dedicated memory processing unit (MPU) intended to pair with TPUs and offload memory-centric work through in-memory processing techniques. Offloading can reduce host-to-accelerator bandwidth and on-die memory pressure by performing prefetching, compression, activation quantization, gather/scatter, and other data-movement operations in a proximity device. The second chip is a next-generation TPU designed specifically for inference, complementing rather than replacing Ironwood.

• •`Ironwood` / `TPU v7` is already positioned as an inference-era accelerator, scaling to 9,216 liquid-cooled chips per superpod and delivering very large FP8 exa-scale throughput; earlier public figures cite peak performance and high-bandwidth memory configurations (for example, 192 GB HBM and multi-petaflop-class arithmetic on preceding v7 variants).
• •The MPU+TPU split mirrors broader system design patterns where a smaller, cheaper companion ASIC handles memory-system functions, enabling the main accelerator to optimize for matrix compute density and energy efficiency.

The AI compute market is shifting from episodic, training-centric capacity to continuous, inference-driven costs that scale with usage. Google has signaled that inference will dominate its compute spend; adding a design partner focused on inference-optimized and cost-tiered silicon allows more aggressive product segmentation. This follows Broadcom's long-term agreement with Google through 2031 for high-performance TPU variants, and MediaTek's role in cost-optimized e variants at lower price points. The custom ASIC market is expanding rapidly, with projections showing robust growth; this deal, if finalized, would accelerate the trend of multi-vendor design stacks for hyperscale AI.

Splitting memory functions into an MPU can materially change system-level performance trade-offs. For ML engineers and infrastructure teams, the implications are lower latency for serving, higher effective model size per dollar, and a new set of performance knobs around memory tiering, compression, and sparsity handling. For hardware teams, the MPU approach increases emphasis on interposer, packaging, and NIC/networking co-design to preserve throughput and maintain low tail latency under load.

Contract finalization and timelines; whether Marvell's role is full-chip design, IP block integration, or design services; silicon process node choices and packaging strategy; and the cost and power targets for the inference TPU versus Ironwood. Also watch software support: runtime, compiler, and graph-partitioning changes needed to offload memory ops to an MPU and preserve model accuracy and determinism.

This is a pragmatic supply-chain and microarchitecture move that signals Google doubling down on inference economics. If executed, MPU+TPU pairings will broaden the hardware choices for serving large models and push other hyperscalers and vendors to adopt similar heterogeneous ASIC strategies.
